SuperTran continuous flow cryostats

ST-100

SuperTran cryostat features

  • <2 K to 325 K (500 K option)
  • Can use either LHe or LN2
  • Sample-in-vacuum

Popular models

Lake Shore — environment by JANIS

With an extensive range of field-proven applications and a worldwide installation base, Lake Shore SuperTran represents the state-of-the-art in continuous flow cryostat design. Using liquid helium (LHe) or liquid nitrogen (LN2), most of the systems provide fast (15 min or less to 4.2 K with LHe) cooldown, a <2 K to 325 K total operating range, and precise temperature control capability in an economical and easy-to-use package.

All systems consist of a cold finger, radiation shield, sample holder, lightweight aluminum vacuum shroud, electrical feedthrough ports, and a high-efficiency flexible 6 ft cryogen transfer line. SuperTran cryostats can be operated in any orientation with only minor variations in efficiencies. Sample temperatures are varied by means of a heater attached to the cold finger. The sample mount and all standard Lake Shore sample holders have provisions for thermometry which, in conjunction with an optional temperature controller, allow precise control over sample temperature.

ST part numberOpticalSizeApplication-specificUHVVibrationMaximum temperature
ST-100    325 K
ST-100-FTIR FTIR  325 K
ST-200     325 K
ST-300SSub-compact   325 K
ST-300T Compact   325 K
ST-300-MS Microscopy  325 K
ST-300-MS UCUltra-compactMicroscopy  325 K
ST-400N/AN/A  500 K
ST-500 Microscopy 15 nm475 K
ST-500-UCUltra-compactMicroscopy 15 nm325 K
ST-500-UHV Microscopy15 nm325 K


Cooling typeLHe
Minimum temperature2 K
Maximum temperature325 K options for 475 K and 500 K
VibrationOptions for low vibration
Sample environmentVacuum
Cooldown15 min (to 5 K)
Sample change time
Typical stability±50 mK
