DT-470-SD Features

• Monotonic temperature response from 1.4 K to 500 K*
• Conformance to standard Curve 10 temperature response curve
• Useful above 60 K in magnetic fields up to 5 T
• The rugged, reliable Lake Shore SD package designed to withstand repeated thermal cycling and minimize sensor self-heating
• Variety of packaging options

DT-471-SD Features

• Lower priced version of DT-470 with a temperature range of 10 K to 500 K*

DT-414 Features

• Temperature range: 1.4 K to 375 K (calibration up to 325 K)
• Small mass for rapid thermal response
• Non-magnetic package

DT-421 Features

• Temperature range: 1.4 K to 325 K**
• Non-magnetic package
• Exposed flat substrate for surface mounting

* Calibrated to 500 K, uncalibrated (Curve 10) to 475 K
** Calibrated down to 1.4 K, uncalibrated (Curve 10) to 20 K

DT-670-SD Features

• Best accuracy across the widest useful temperature range – 1.4 K to 500 K – of any silicon diode in the industry
• Tightest tolerances for applications from 30 K to 500 K of any silicon diode to date
• Rugged, reliable Lake Shore SD package designed to withstand repeated thermal cycling and minimize sensor self-heating
• Conformance to standard Curve DT-670 temperature response curve
• Variety of packaging options

DT-670E-BR Features

• Temperature range: 1.4 K – 500 K
• Bare die sensors with the smallest size and fastest thermal response time of any silicon diode on the market today
• Non-magnetic sensor

DT-621-HR Features

• Temperature range: 1.4 K – 325 K*
• Non-magnetic package
• Exposed flat substrate for surface mounting

* Calibrated down to 1.4 K, uncalibrated (Curve DT-670) to 20 K
